Emlid RS2 GNSS Receiver – Base 198,000.00 excl. GST
Description
Gets a fix in seconds

Reach RS2 gets a fixed solution in just seconds and maintains robust performance even in challenging conditions. Centimeter accuracy can be achieved on distances up to 60 km in RTK, and 100 km in PPK mode.
GPS, GLONASS, BeiDou,
Galileo, and QZSS
L1OF, L2OF, L1C/A, L2C,
E1B/C, E5b, B1I B2I

PPP Support

RINEX raw data logs are compatible with PPP services so you can now get centimeter-precise results in any place on Earth. Process RINEX files in an online service and get position with absolute accuracy.

Built-in 3.5G modem

Reach RS2 features a power-efficient 3.5G HSPA modem with 2G fallback and global coverage. Now corrections can be accessed or broadcasted over NTRIP independently, without relying on an Internet connection on your phone.

22 hours on 1 charge

Up to 22 hours of autonomous work when logging data and up to 16 hours as a 3G rover, even in cold weather—no more need to carry spare batteries with you. Reach RS2 can charge from a USB wall charger or a power bank over USB-C.

SPECIFICATIONSTECHNICAL DATA
MakeEMLID
ModelRS2
Base station modelRS2
Rover modelRS2
Controller modelOEM provided ReachView App which helps any smartphone work as advanced field Controller
No.of channels184
Static Horizontal accuracy (Long observation)4 mm
Static Vertical accuracy (Long observation)8 mm
Static Horizontal accuracy (Fast static)4 mm
Static Vertical accuracy (Fast static)8 mm
RTK Horizontal accuracy7mm+1ppm
RTK Vertical accuracy14mm+1ppm
Distance range with RadioUp to 3-5 km
Distance range with GSM30km
Post processing SoftwareOEM provided post processing software
List of accessories• 2 Wooden Telescopic Tripod
• 1 Pole for Rover
• 1 Cradle for Controller
• 2 Tribraches for Static Survey
• 1 Data Collection Software
• 1 Post Processing Software
• 4 Batteries
• 2 Containers (with all Standard cables & accessories)
Warranty12 months
