Amass QS10-S High Temperature Antispark Battery Connector Female

Amass QS10-S High Temperature Antispark Battery Connector Female

The Amass QS10-S Female Plug is a premier heavy-duty electrical interface built for high-voltage energy storage systems. This female connector is engineered to handle extreme current demands safely without failure. It is widely adopted across the light electric vehicle sector for motorcycles and bicycles. Furthermore, its reliable structure makes it a vital component for industrial UAVs and agricultural drones. The Amass QS10-S Female Plug provides a secure bridge between your high-capacity battery pack and speed controllers. It handles continuous high power while maintaining low contact resistance across the system. This ensures that your machinery receives clean energy with minimal transmission loss during heavy workloads. Operators can deploy this connector confidently in demanding field environments.

Advanced Anti-Spark Technology

Connecting high-voltage batteries to an ESC often creates massive and destructive electrical sparks. Therefore, the Amass QS10-S Female Plug features an integrated anti-spark mechanism. This smart system utilizes a built-in resistor to absorb initial current surges during mating. Consequently, it eliminates connection sparks entirely to preserve your precious electronic circuits. By mitigating these spikes, the plug dramatically reduces terminal erosion and pitting over time. It guarantees an exceptional operational life of over 1000 plug-in cycles. This safety feature protects the user from accidental flash hazards during system assembly. It also ensures that the internal gold-plated bullet terminals stay pristine for long-term conductivity.

Key Features

• Advanced anti-spark integration to protect electronics from power surges.

• Robust 10mm gold-plated copper contacts for maximum current throughput.

• Handles up to 180A continuous current and 240A instantaneous bursts.

• High-grade PA insulation material with a UL94-V0 flame-retardant rating.

• Broad operational temperature threshold spanning from -30°C to 150°C.

• Eliminates the need for heat shrink tubing via attached wire covers.

• Designed to accommodate thick high-current cables from 4AWG to 10AWG.

• Extremely low contact resistance of 0.51 mΩ for minimal energy loss.

Rugged Build and Application

Industrial power setups require hardware that survives extreme heat and physical vibrations. The shell of this connector is manufactured from rugged nylon infused with glass fiber. Because of this material choice, it resists melting and cracking under high thermal strain. This makes it perfect for heavy-lift multirotors and electric bike conversions. The included rear wire covers shield your solder connections from dirt and environmental moisture. Additionally, they provide an extra layer of mechanical strain relief for the heavy gauge wires. The Amass QS10-S Female Plug is simple to install and solder for professional builders. It brings safety, neatness, and industrial compliance together in a single package.

Technical Excellence

When managing large power banks, choosing a generic connector can result in costly hardware failure. This authentic Amass component delivers unmatched precision and dimensional accuracy. It fits seamlessly with its male counterpart to create an airtight and vibration-proof locking union. The tight tolerance prevents accidental disconnections during high-speed operations or rough flights. Ultimately, this high-temperature female plug is a vital investment for serious DIY battery builders. It ensures peak performance for any machine demanding stable high-amp distribution.
