Flameback 2415 KV 1200 BLDC Drone Motor 3,299.00 excl. GST
Description

Flameback 2415 KV 1200 BLDC Drone Motor

Flameback 2415

  1. 1200 KV, 12N14P configuration
  2. Max power 800 W, 50 A current
  3. Supports 4S LiPo battery
  4. Ø24 × 15 mm stator size
  5. Weight 90 g including cables
  6. Responsive throttle, optimized for agility
  7. Recommended ESC: 50A
  8. Recommended propellers: 11 × 4.5
  9. ISO 9001 Certified Quality

Description

The Flameback 2415 KV1200 BLDC Motor is designed for high-performance multirotor and hybrid drone platforms requiring speed, agility, and reliable power. With a 1200 KV rating, 12N14P configuration, and 800 W continuous output, it provides responsive throttle control and consistent efficiency for demanding aerial applications.

Its compact 24 × 15 mm stator design delivers smooth acceleration, while optimized winding and premium lamination ensure reduced heat buildup and durability under aggressive flight conditions. Ideal for lightweight quads, VTOLs, and fixed-wing UAVs, the 2415 KV1200 strikes the perfect balance of agility and control.

Features

  • High Power Output: 800 W continuous power with 50 A max current.
  • Optimized KV Design: 1200 KV, 12N14P configuration ensures agility and speed.
  • Compact Stator Build: 24 mm diameter × 15 mm height enables efficient power delivery.
  • Smooth Control: Provides responsive throttle for VTOLs and lightweight UAVs.
  • Efficient Operation: Designed for 4S LiPo batteries for maximum compatibility.
  • Thermal Efficiency: Premium lamination stacks reduce heat buildup during sustained flight.
  • Durable Construction: Built for extended operation under demanding flight profiles.
  • Recommended Setup: Works best with 50A ESC and 11×4.5 propellers.

Warranty
This product is covered by a 12-month standard supplier warranty, valid from the date of delivery. The warranty applies to manufacturing defects only, and replacement will be provided in such cases.

The warranty does not cover issues resulting from misuse, tampering, static discharge, accidents, water or fire damage, exposure to chemicals, or if the product has been soldered, modified, or altered in any way.



Specifications
ParameterSpecification
Item TypeDrone motor
Model TypeBLDC Motor
Motor KV (RPM/V)1200
Motor TypeBrushless Motor
Max. Power (W)800
Current Rating (A)50
Stator Height15 mm
Stator Diameter24 mm
Configuration12N14P
Compatible Prop (inch)11 × 4.5
Compatible LiPo Batteries4S
Operating Temperature (°C):-20 – 125°C
Weight (g)90 (including cables)
