Flameback 4006 320KV BLDC Drone Motor

Flameback 4006 320KV BLDC Drone Motor

Flameback 4006

1. >2 kg thrust, 70 g weight
2. 320 KV, 18N24P configuration
3. Max power 350 W, 18 A current
4. Supports 4-6S LiPo batteries
5. Ø45.5 × 32 mm dimensions
6. Finned design for thermal cooling
7. Flux rings for rotor stability
8. Recommended ESC: 45A 6S, Props: 14×4.8 / 15×5.5
9. ISO 9001 Certified Quality

Description:

The Flameback 4006 KV320 BLDC Motor is engineered for UAV applications that demand a balance of thrust, stability, and efficiency. Delivering over 2 kg of thrust at just 70 g weight, this motor supports 4-6S LiPo batteries and provides up to 350 W continuous power (300s). With its 18N24P configuration and unique finned design, it ensures excellent thermal management, smooth flight dynamics, and dependable performance in demanding environments.

Ideal for delivery drones, mapping UAVs, and aerial photography platforms, the Flameback 4006 KV320 combines lightweight construction with durability, making it a trusted choice for drone builders and UAV developers.

Features:

1. Optimized Power-to-Weight Ratio: Generates over 2 kg thrust with only 70 g weight, enabling efficient lift for medium-lift UAVs.
2. Advanced Thermal Design: Integrated finned housing ensures superior heat dissipation for consistent performance under extended flights.
3. Rotor Balance Technology: Precision flux rings reduce inertia and vibration, delivering smoother and more stable flight control.
4. Rugged Construction: High-strength build withstands demanding operating conditions without compromising efficiency.
5. Environmental Protection: Sealed against dust and moisture ingress for reliable outdoor operation.
6. Corrosion-Resistant Stator: Engineered for durability in humid and coastal climates.
7. Shock and Impact Resilience: Robust structure tolerates hard landings and handling stress.
8. Seamless Integration: Recommended with Flameback 45A 6S ESC and 14×4.8 / 15×5.5 propellers for optimal system performance.

Warranty:
This product is covered by a 12-month standard supplier warranty from the date of delivery, limited to manufacturing defects only. Replacement will be provided in such cases.
Please note, the warranty will be void if the product is misused, tampered with, exposed to static discharge, accident, fire, water, or chemicals, or if it has been soldered, modified, or altered in any way.

Detailed specifications are available in the Specifications tab.
