HOBBYWING X6-SE 280KV Motor CCW

HOBBYWING X6-SE 280KV Motor CCW

The Hobbywing X6-SE 280KV Motor CCW is a heavy-duty, high-performance industrial brushless outrunner motor engineered specifically for medium-to-large multirotors and enterprise drone platforms. Built on a robust 6208 stator specification, this power plant delivers incredibly stable and highly efficient lift dynamics. When paired with a 6S LiPo battery system and 2270 folding propellers, it generates a massive maximum thrust of up to 6.2kg per rotor. The integrated housing is designed to clamp directly onto a standard 25mm carbon fiber arm tube, drastically simplifying your aircraft’s structural footprint. Outfitted with native CAN protocol support for smart digital communication, this Counter-Clockwise (CCW) rotation variant serves as an ideal foundation for industrial utility drones.

Key Features

• Optimized 280KV Power Curve: Engineered to provide a balanced torque-to-speed ratio for heavy industrial payloads.

• Massive Lift Profile: Generates a maximum peak thrust of 6.2kg per rotor, easily supporting heavy drone platforms.

• Direct 25mm Arm Mounting: Features an integrated base clamp built specifically to slide over and lock onto 25mm carbon fiber arm tubes.

• Smart CAN Protocol Data Loop: Enables real-time digital communication for monitoring vital motor diagnostics, telemetry, and operating states.

• Efficient 6S Battery Platform: Optimized to run cooler and pull current safely from standard 6S Lithium-Polymer battery banks.

• High Power Threshold: Handles high-amperage throttle punches with a maximum power rating of up to 1070W.

• Integrated Lightweight Design: The motor and structural mount weigh only 373g (±15g) with propellers attached, reducing overall dead weight to maximize flight times.

• Industrial Thermal Dissipation: An open-air outrunner shell structure actively forces air through the internal core to keep operational temperatures low.

Applications

Commercial flight crews install the Hobbywing X6-SE 280KV Motor CCW into heavy-lift quadcopters and hexacopters to maintain rock-solid stability during high-resolution aerial photography and photogrammetry missions. Its built-in reliability and continuous payload capacity make it a perfect choice for industrial infrastructure inspection flights around wind turbines and high-voltage power grids. Agricultural mapping teams rely on its stable 2-2.5kg recommended cruise thrust to execute precision spraying and multispectral field analysis. Additionally, it serves as a highly robust, failure-free propulsion unit for engineering universities, UAV training institutes, and custom industrial drone developers.

System Integration and Flight Physics

To achieve perfect aerodynamic torque balancing across your multirotor chassis, this CCW-rotating motor must be distributed in equal pairs with its Clockwise (CW) counterpart. The integrated motor clamp attaches firmly to 25mm carbon fiber tubes, ensuring perfect alignment without needing heavy external adapter plates. Utilizing its smart CAN protocol layout, the motor streams real-time operating metrics straight to compatible flight controllers. To secure maximum energy efficiency and smooth flight characteristics under variable wind conditions, it is highly recommended to pair this motor with Hobbywing’s matching 2270 carbon-plastic folding blades.
