ADTI 24MP APS-C Mapping Camera Surveyor 24L

24L V2 Surveyor Lite Mapping Camera

High-Performance Drone Mapping Camera

The 24L V2 Surveyor Lite is ADTi’s third-generation 24MP APS-C drone/UAV mapping camera, designed to deliver exceptional imaging performance. Featuring the ADTi SDK camera controlling system, it is fully compatible with AirPixel for PIX4 and Ardupilot MAVlink, ensuring seamless integration into advanced drone mapping setups.

Enhanced Cooling Efficiency

Equipped with an upgraded active cooling fan, the 24L V2 offers better efficiency and lower power consumption compared to the V1 Surveyor Lite. This improvement ensures optimal thermal performance, enhancing camera longevity and reliability in demanding aerial applications.

Advanced Wireless Connectivity & HDMI Support

With an integrated Bluetooth module, this camera allows for wireless camera setting adjustments, eliminating the need for cumbersome wired connections. Additionally, its HDMI video capture card enables real-time connection with Android devices, offering a convenient way to monitor and configure camera settings on the go.

Compact and Lightweight Design

The 24L V2 Surveyor Lite is built for efficiency, with a camera body weighing only 122g. Its compact dimensions (776238.7 mm) make it an ideal choice for drone applications, ensuring minimal impact on the drone’s payload capacity. The ABS injection-molded case adds durability while keeping the design lightweight.

Superior Imaging Capabilities

This camera is powered by a 24.3MP APS-C Sony CMOS sensor, delivering high-resolution imagery with precise details. The sensor format (APS-C, 366.6mm²), 3.92-micron pixel pitch, and 1.5x focal length multiplier contribute to its exceptional imaging quality. It supports a color depth of 23.8 bits and a maximum effective ISO of 1,347, ensuring optimal performance in various lighting conditions.

Versatile Image & Video Capture

• Image Resolutions: Up to 6000 x 4000 (24.0 MP) with multiple aspect ratios.
• Image Formats: JPEG, RAW, and RAW+JPEG for flexible post-processing.
• Video Resolutions: Full HD 1920×1080 (60p/30p/24p) with support for XAVC S, AVCHD 2.0, and MP4 formats.
• HDMI Output: Enables high-quality video transmission to external displays.

Precision Lens and Optics

• Lens Mount: Sony E-mount
• Focus Range: 25 cm to Infinity
• Auto & Manual Focus: Provides complete control over image sharpness

User-Friendly Display & Power Efficiency

• Detachable 2-inch mini touch screen for intuitive control
• Power Input: 10-25V DC (LiPo or Li-ion compatible)
• Operating Temperature: -10 to 40°C, making it suitable for diverse environmental conditions

Optimized for Drone Mapping Applications

The 24L V2 Surveyor Lite Mapping Camera is engineered for precision, efficiency, and seamless integration with UAV mapping systems. With its compact form factor, wireless capabilities, and superior imaging performance, it stands out as a top-tier choice for professional aerial mapping, surveying, and remote sensing projects.
